Mobile Home Leveling
Precision leveling and re-leveling that stops sticking doors, cracked walls, and sagging floors — and keeps your home stable for the long haul.
A mobile home that sits even a little out of level puts stress on everything above it. Doors bind, drywall cracks, floors slope and plumbing strains. Leveling spreads the home’s weight evenly across its piers so the structure sits true and stays that way — and there is a measurable standard for when it is right.
How level does a mobile home have to be?
A manufactured home counts as adequately leveled when there is no more than a 1/4 inch difference between adjacent pier supports — under the frame or around the perimeter — and every exterior door and window opens, closes and latches without binding. That is the federal test, in 24 CFR 3285.6, and it is the one we measure against. Some states add a second limit: Ohio, our home state, also requires that no point on the frame differ by more than 1/2 inch from the comparable point on the opposite side or end (Ohio Admin. Code 4781-6-03.8). The door-and-window check is part of the standard, not a folk remedy — a frame out of plane shows up at the openings first.
How a mobile home is leveled, step by step
Leveling is a sequence, and the order matters more than the equipment. This is how our crews work a job:
- Survey first. We shoot the main rails and the perimeter with a laser or water level and record every pier’s deviation, so we correct a measured picture rather than chase a sagging floor by feel.
- Release the tie-downs. Straps left under tension fight the jacks and can pull an anchor out of plumb.
- Lift at the frame. Hydraulic jacks go under the main I-beam on a solid base — never under the floor, the outriggers or the bottom board, all of which will dent or tear.
- Work outward from the center. On a multi-section home that means starting at the mate line, so the frame comes back into plane instead of being twisted into a new shape.
- Reset the pier, not just the shim. If the footing has sunk or broken, the pier is rebuilt on a sound one. Crushed caps are replaced: a cap must be solid concrete or masonry at least 4 inches nominal, hardwood at least 2 inches nominal, or corrosion-protected steel at least 1/2 inch thick, and it has to match the pier it sits on.
- Shim in pairs. Opposed pairs, nominal 4 by 6 by 1 inch, driven tight so the pair takes up no more than one inch of height. Anything left is made up with hardwood plate no thicker than 2 inches nominal, or a 2- or 4-inch block — not a stack of shingles. Adjustable risers on manufactured piers should not extend more than 2 inches in their final position.
- Re-check, re-tension, then test the doors. Adjacent piers are re-measured against the 1/4 inch rule, the tie-downs are brought back to the anchor manufacturer’s specified tension, and every exterior door and window is operated before we call the job done.
What our leveling service includes
- Full inspection of piers, footings, and the frame’s current level
- Adjusting, adding, or resetting piers to carry the load correctly
- Precise shimming to bring the frame back into true
- Checking doors, windows, and floors after leveling
- Advice on drainage or soil issues that cause repeat settling
Mobile home piers: spacing, height and load limits
Leveling is only as good as the piers underneath, and piers have hard limits. Frame piers must sit within 24 inches of each end of the home and no more than 120 inches — 10 feet — apart on center under the main rails (24 CFR 3285.310). Load-bearing block is nominal 8 by 8 by 16 inches, laid cells vertical and long side square to the beam. Under 36 inches a pier can be a single stack; from 36 to 67 inches it must be double, interlocked block; over 67 inches it needs an engineer’s design. Top-to-bottom horizontal offset may not exceed 1/2 inch on a single stack or 1 inch on a double.
Capacity is where cheap work shows up. A single-stacked 8-by-16 block pier is limited to 8,000 pounds and a double-stacked 16-by-16 pier to 16,000, and each pier needs its own footing bearing on undisturbed soil or fill compacted to 90 percent of maximum relative density. A 16-by-16 inch footing on 1,000 psf soil carries only about 1,600 pounds; 24 by 24 inches takes it to roughly 3,700 (24 CFR 3285.312). So “just add another shim” is usually wrong: an undersized footing keeps sinking however often the home is jacked up.
Why homes go out of level — and how to stop it coming back
Most repeat settling is a water problem wearing a pier problem’s clothes. The ground around a manufactured home should fall at least 1/2 inch per foot away from the foundation for the first 10 feet; where the site will not allow that, it needs drains, swales or regrading (24 CFR 3285.203). We look at the grading as well as the piers, because correcting the frame without correcting the water just buys you two years.
In freezing climates the footing is the issue: footings must sit below the local frost line unless the foundation is an engineered monolithic slab or insulated design. A home that goes out of level every spring is usually heaving, not settling.
What mobile home leveling costs
We quote leveling per job rather than off a price list, because the drivers vary so widely: how many piers come out and go back, whether the footings under them are sound or have to be rebuilt to frost depth, how much crawl-space clearance the crew has, whether the drainage has to be corrected at the same time, and whether the home is a single wide or a multi-section that must also come true across the marriage line. Send us the details and we will put a number on it.
Single wide vs. double wide leveling
A single wide is leveled as one frame. A double wide has to be leveled so both halves sit true to each other across the marriage line — if one section drops, the seam pulls apart and the whole floor plane goes off. Multi-section homes take more measuring and adjusting to get the entire structure sitting flat as a unit, and that is exactly the kind of work our crews do regularly.
Leveling rarely travels alone: lifting a home slackens its tie-downs, so the anchoring has to be re-tensioned afterward, and a freshly hauled home needs its blocking and setup checked first. One crew, one visit.
Why choose us for leveling
- Experienced crews with the right hydraulic equipment
- We fix the cause, not just the symptom
- Single wide, double wide, and multi-section homes
- Leveling coordinated with setup and anchoring in one visit
Leveling FAQs
The federal installation standard treats a home as adequately leveled when there is no more than a 1/4 inch difference between adjacent pier supports — under the frame or around the perimeter — and the exterior doors and windows open, close and latch without binding (24 CFR 3285.6).
It depends on how many piers have to be reset, whether the footings under them are still sound, how much working room there is under the home, and whether the drainage that caused the settling has to be corrected too. We quote leveling per job after looking at the home rather than off a price list.
Common warning signs are doors and windows that stick or won’t latch, cracks in drywall or above door frames, sloping or bouncy floors, and gaps opening between walls and ceilings. If you notice any of these, the home has likely settled and needs re-leveling.
There is no federally mandated interval — it is condition-driven. We recommend a check every two to three years, plus one after the home’s first full freeze-thaw cycle on a new site and any time the ground nearby is dug up, regraded or flooded. Soft, expansive or freshly graded soil settles faster.
Often, yes. When those problems come from the home settling out of level, correcting the pier support and bringing the frame back to true relieves the stress and lets doors, windows, and walls return to normal. Severe long-term damage may need additional repair.
Yes. We level single wide, double wide, and multi-section homes. Double wides need both halves leveled to each other across the marriage line, so the whole floor plane sits true — a bit more involved than a single wide.
